TPS2372-4RGWT Integrated Circuit Chip High-Power PoE PD Interface With Automatic MPS And Autoclass
Product Description
The TPS2372-4RGWT contains all features required to implement an IEEE802.3at or IEEE802.3bt powered device. With low internal switch resistance, it supports high-power applications up to 90W, delivering 71.3W and 51W at PD input when using 100-meter CAT5 cable.
Specifications
| Type |
Controller (PD) |
| Number of Channels |
1 |
| Power - Max |
90 W |
| Internal Switch(s) |
Yes |
| Auxiliary Sense |
No |
| Standards |
802.3at (PoE+), 802.3bt |
| Voltage - Supply |
0V ~ 57V |
| Current - Supply |
550µA |
| Operating Temperature |
-40°C ~ 125°C (TJ) |
Key Features
- IEEE 802.3bt (Draft) PD Solution for Type 4 PoE
- Supports Power Levels for Type-4 90-W Operation
- Robust 100 V Hotswap MOSFET
- TPS2372-4 (typ.): 0.1-Ω, 2.2-A Current Limit
- Allocated Power Indicator Outputs
- PG Output with Inrush Completion Delay
- Compliant to PSE Inrush
- Automatic Maintain Power Signature (MPS)
- Auto-adjust MPS for Type 1-2 or 3-4 PSE
- Supports Ultra-Low Power Standby Modes
- Supports Autoclass Operation
- Supports PoE++ PSE
- -40°C to 125°C Junction Temperature Range
- 20-lead VQFN Package
Applications
IEEE 802.3bt (Draft) Compliant Devices, Lighting, Power Modules, Dual Signature PD/Forced UPOE, 4PPOE, Pass-through System, Security Cameras, Multiband access points, Pico-base Stations
