Product Description Of NCF3340AHN
NCF3340AHN is ideally suited for easy integration of NFC technology into cars because it provides an NCI interface, a small PCB footprint, a small external BOM, and the capability to achieve full NFC Forum compliance with a small form-factor antenna.

It uses an optimized architecture for low power consumption and integrates a highly efficient power management unit. It supports high output power by supplying the transmitter output stage up to 5.5 V. This enables a large operating distance in Reader/Writer mode.

The contactless front-end has also high sensitivity and supports active load modulation mode. The device ships in a 40-pin HVQFN package with wettable flanks.

Specifications Of NCF3340AHN

Features Of NCF3340AHN
Supports Reader/Writer mode with multiple protocols incl. ISO/IEC 14443 A, ISO/IEC 14443 B, FeliCa and ISO/IEC 15693
Supports Passive and Active Peer to Peer mode with full NFCIP-1 and NFCIP-2 compliance
Supports Card Emulation mode in accordance with ISO/IEC 14443 A and FeliCa
Supported host interfaces: SPI bus, I²C bus, NCI protocol interface according to NFC Forum NCI standardization
Internal oscillator for 27.12 MHz crystal
Integrated PLL unit for use with an external reference clock
An integrated power management unit
Voltage supply: 2.3 to 5.5 V
Autonomous mode when the host is shut down
Automatic wake-up via RF field and an internal timer

Benefits Of NCF3340AHN
Fully automotive qualified
Full NFC Forum compliance
Integrated firmware with NCI interface
Fast time-to-market
Low bill of materials(BOM)
Easy development
Proven interoperability
Low power operation

Applications Of NCF3340AHN
BT@Wi_Fi@pairing
Driver authorization (e.g., engine start)
Personalization (air conditioning, seat features and mirror settings)
Transmit vehicle diagnostics data
Payment services
